NDT and Security

JRX-iQ


Our new JRX-iQ is a portable all in one multi modality workstation. It boasts over 8 hours of battery life per charge. The fastest refresh time of any Flat Panel System on the market today of under 3 seconds.The JRX-iQ uses 3rd generation TFT technology with our 14x17 Flat Panel Detector which offers Ultimate strength and stability. This systems also integrates for use with Ultrasound, Endoscopy and more. Simple touchscreen interface using GoDR Acquisition Software.



JRX-iQ 1417 DR Panel offers a powerful X-ray imaging solution for NDT (Non-Destructive Testing), EOD (Explosive Ordnance Disposal) and Security with industry-leading performance and cutting-edge features. The all in one design offers ultimate portability with unmatched image quality. Our innovative technology contains multiple TFTs in a pixel resulting in ultra-high resolution, ultra-low noise, and a very high dynamic range. The JRX-iQ has two sides that offer minimal dead space which provides dramatically minimized loss of imaging area.

NDT 1012MA


Wireless Portable FPD for Industrial NDT and Security Systems

NDT 1012MA is a 10×12-inch wireless and portable amorphous silicon flat panel detector. The detector features a compact and industrially rugged design, which provides high radiation resistance, wide environmental capabilities, and overall high reliability. Data and signal communication is achieved either via a wired or a wireless interface. The iRay software SDK provides support for detector calibration, configuration, image acquisition, pre-processing and viewing on an end-user tablet or workstation running the MS Windows operating system. With its exceptional image quality and reliability, the NDT 1012MA is an excellent choice for portable field inspection applications or IED/EOD based security scenarios.

Features

  • Proven radiation hard a-Si design
  • 25×30 cm² imaging area
  • 125 μm pixel pitch with 16-bit ADC for more image details
  • Up to 180 sec. X-ray exposure window
  • Rugged design, withstand 1m drop
  • Robust wired and 5G wireless data interface
  • Narrow dead space edge (< 7 mm)
  • 2.5 hours battery capacity

NDT 1417LA


14×17-inch Flat Panel Detector for Real-Time Imaging

NDT 1417LA is a 14×17-inch wireless and portable flat panel detector based upon iRay’s innovative and unbreakable flexible sensor technology. The detector features a compact and industrially rugged design, which provides high radiation resistance, wide environmental capabilities, and overall high reliability. Data and signal communication is achieved either via a wired or a wireless interface. The iRay software SDK provides support for detector calibration, configuration, image acquisition, pre-processing and viewing on an end-user tablet or workstation running the MS Windows operating system. With its exceptional image quality and reliability, the NDT 1417LA is an excellent choice for industrial applications such as portable field inspection, or EOD/IED based security scenarios.

Features

  • Innovative flexible a-Si sensor technology
  • 35×43 cm² imaging area
  • Best-in-class 100 μm pixel pitch with 16-bit ADC for more image details
  • Up to 180 sec. X-ray exposure window
  • Robust wired and 5G wireless data interface
  • Thin and lightweight design with narrow dead space edge (7 mm)
  • More than 5 hours battery capacity

NDT (Non-Destructive Testing)


Using an expensive DR Panel in a portable / mobile environment can be extremely risky. You can easily reduce that burden by protecting your investment with one of our innovative NDT Panel Protectors. This product is perfect for field use in harsh environments such as Bridges, Pipelines, Ships, Refineries and Home Land Security.
